Type tested Main Switchboards & Motor Control Centres
Type tested to 63kA for 3seconds on main busbar
50kA for 1 second on droppers up to 40x6.3 copper bar for
Type tested functional outgoing units
Co-ordination of equipment
Type 1 & type 2 we have type tested boards with the following features
Fault rating up to 100kA for 1 second & 65kA for 3 seconds
Current rating from 600 to 3400 Amps (4000 Amps incomer)
Impulse withstand voltage (Uimp) up to 16kV (busbar system)
Insulation voltage (Ui) up to 1000V AC
Operating voltage (Ui) up to 690V
Dielectric withstanding of 3.5kV
Internal arcing – fault test 50kA up to 690V
Approvals
CE marked
Lloyds
Materials
Body – zinc coated steel
Body thickness – 1.6/1.5mm
Gasket – FIP polyurethane
Surface finish – powdercoated
Protection rating – IP43 to IP55
Arc fault containment “form 3b and form 4 range of low voltage switchgear and control gear assemblies have been extensively type tested by Testing and Certification Australia to comply with the requirements of AS/NZS3439.1 1993 APP EE and AS/NZS3439.1 2002”
“Signature SE is our switchboard building system for Low Voltage Switchboards and Motor Control Centres that fully complies with AS/NZS 3439.1-2002”.
“Comprehensive range of ASTA type test certificates includes all seven type tests. These tests include:
verification of temperature rise limits
verification of dielectric properties
verification of short circuit withstand strength
verification of continuity of protective circuit
verification of clearances and creepage distances
verification of mechanical operation
verification of degree of protection
In addition to the above test additional testing has been undertaken to prove the ability of Signature SE to withstand the effects of internal arcing fault test”.
